Output Nominal Voltage

100; 120; 127

Customized Load Management

Receptacles

8 individually switched output receptacles

USER INTERFACE, ALERTS & CONTROLS

Front Panel LCD Display

Digital display reports total PDU output current in amps

Front Panel LEDs

8 LEDs display power on-off status for each output receptacle

SURGE / NOISE SUPPRESSION

Automatic Shut-Off

No

PHYSICAL

Material of Construction

Metal

Form Factors Supported

1U rackmount

Minimum Required Rack Depth (cm)

23.62

Minimum Required Rack Depth

(inches)

9.3

PDU Form Factor

Horizontal (1U)

Shipping Dimensions (hwd / cm)

29.72 x 5.08 x 51.31

Shipping Dimensions (hwd / in.)

11.70 x 2.00 x 20.20

Shipping Weight (kg)

3.54

Shipping Weight (lbs.)

7.80

Unit Dimensions (hwd / in.)

1.75 x 17.5 x 4.25

Unit Dimensions (hwd / cm)

4.44 x 44.4 x 10.8

Unit Weight (lbs.)

5.99

Unit Weight (kg)

2.72

ENVIRONMENTAL

Storage Temperature Range

5 to 122F (-15 to 50C)

Relative Humidity

5-95% non condensing

Operating Elevation (ft.)

0-10,000

Operating Elevation (m)

0-3000

COMMUNICATIONS

PowerAlert Software

LX Platform Interface: PowerAlert Device Manager

Communications Cable

RJ45-to-DB9 configuration/console Access cable

Network Monitoring Port

RJ45 Network port, Micro-USB Configuration port, USB A port supports a variety of Envirosense2 environmental and

control modules. See Accessories>Management Hardware section for more information about these modules.
