PowerAlert Console Launcher To address Java Runtime Environment (JRE) issues with respect to the

SNMPWEBCARD web interface, Tripp Lite recommends using the PowerAlert Console Launcher . This

application enables local access of the SNMPWEBCARD using a self-contained, compatible JRE version.

The Console Launcher can be downloaded for free from the Technical Support page or from the

Management Solutions / Utilities page.

1.9kW Single-Phase Switched PDU, 120V Outlets

(8 5-15/20R), L5-20P/5-20P Adapter, 12ft Cord, 1U

Rack-Mount, TAA

MODEL NUMBER: PDUMH20NET2

Description

Tripp Lite single phase Switched PDU / Power Distribution Unit offers advanced network control and

monitoring with the ability to turn on, turn off, recycle or lock-out power to each individual receptacle,

monitor site electrical conditions and remotely monitor output power consumption. PowerAlert interface

supports remote control and custom notification of user-specified conditions via email, PowerAlert

Console Launcher, SNMP, Telnet or SSH interface. Individually switched outlets can be controlled in real-

time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined

power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent

inrush-related overloads as network equipment is first energized. Unused PDU outlets can be

electronically locked off to prevent the connection of unauthorized hardware. PDU output current

consumption in amps is continuously displayed locally via visual meter and remotely via the network

interface to warn of potential overloads before critical IT mains or branch breakers trip.

Features

20A 120V Switched Power Distribution Unit / PDU with built-in network interface (Agency derated to

16A continuous)

q

Attached NEMA L5-20P input with NEMA 5-20P plug adapter, 12 ft. / 3.6m input cable

q

1U horizontal rackmount form factor

q

8 switched NEMA 5-15/20R outlets

q

Supports power-on, power-off or reboot of each outlet on a real-time or programmable basis

q

Highlights

Switched 20A 120V PDU, 1U

horizontal rackmount format

q

Reports voltage, frequency &

load level via ethernet interface

q

Visual current meter, Reversible

housing

q

NEMA L5-20P input with 5-20P

plug adapter, 12 ft. / 3.6m line

cord

q

8 NEMA 5-15/20R switched

outlets with cord retention

brackets

q

Temperature, humidity and

contact closure monitoring

options

q

Trade Agreements Act / TAA

Compliant for GSA Schedule

purchases

q

Package Includes

PDU with attached L5-20P input

power cord and 5-20P plug

adapter

q

Rackmount installation brackets

and wire retention plates

q

Configuration cable

q

User manual

q
