Specifications

out of phase utility power grid feeds are fully supported

On-board ATS processor constantly evaluates power quality on both inputs to prevent transfer to the

secondary source when unavailable or of lower quality than the primary source

q

LX Platform interface allows full remote access for power monitoring with email notifications via secure

web browser, SNMP, telnet or SSH

q

Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring

capabilities

q

Auto Probe feature (Firmware 15.5.2 and greater) checks the connectivity status of any networked

device and automatically takes one or more user-configured actions if the device fails to respond;

actions include outlet reboot, set SNMP traps, SNMP OID sets, and even script execution when used in

conjunction with the Tripp Lite PowerAlert Network Shutdown Agent (PANSA)

q

Outlets are factory programmed for sequential turn-on at 250 millisecond intervals as the PDU is first

energized

q

Front panel LEDs confirm power availability on both input lines

q

Compliant with the Federal Trade Agreements Act(TAA) for GSA Schedule purchases

q

OVERVIEW

UPC Code

037332157294

PDU Type

Auto-Transfer Switch; Switched

INPUT

PDU Input Voltage

100; 120; 127

Recommended Electrical Service

30A 120V

Maximum Input Amps

30.0

Maximum Input Amps Details

Agency de-rated to 24A continuous

PDU Plug Type

(2) NEMA L5-30P

Input Phase

Single-Phase

Input Cord Details

Set of two inputs connect to separate PRIMARY and SECONDARY power sources

Input Cord Length (ft.)

10

Input Cord Length (m)

3.05

OUTPUT

Output Capacity Details

3.05kW (127V), 2.88kW (120V), 2.4kW (100V) / 30A total capacity (Agency de-rated 24A); 24A max per L5-30R

outlet; 20A max per breakered load bank; 16A max per 5-15/20R outlet

Frequency Compatibility

50 / 60 Hz
