Specifications

componentsNEMA L5-30P plug with 10 ft. cord connects to compatible AC power sourceFirmware

upgrades support future product enhancements

24 Switched Outlets Distribute AC Power24 NEMA 5-15/20R outlets split into 2 separately breakered

load banksIndividual outlets can be remotely controlled to power up, power down, reboot or lock out

devicesCord retention brackets prevent cables from becoming accidentally disconnected

Digital AmmeterReports load level on each bank and total PDU outputSupports IP-address self-

IDRotates 180° for easy reading at either angle

Built-In LX Platform InterfaceAllows full remote access for power monitoring with email notifications via

secure web browser, SNMP, telnet or SSHSupports 10/100 Mbps auto-sensing for communication with an

Ethernet networkOptional EnviroSense2 modules (sold separately) provide a variety of environmental

monitoring capabilitiesNo Java required

Broad Communications CompatibilitySupports HTTP, HTTPS, SMTP, SNMPv1, SNMPv2c, SNMPv3,

telnet, SSH, CLI, FTP, DHCP and NTPSupports automatic and manual assignment of IP address

Reduce Service Calls with Auto Probe Autonomous Device ManagementThe Auto Probe feature

(Firmware 15.5.2 and greater) checks the connectivity status of any networked device and automatically

takes one or more user-configured actions if the device fails to respond; actions include outlet reboot, set

SNMP traps, SNMP OID sets, and even script execution when used in conjunction with the Tripp Lite

PowerAlert Network Shutdown Agent (PANSA)

Easy 0U Installation in EIA-Standard 19 in. RacksMounts vertically using included toolless buttons or

rack-mounting bracketsIncluded PDUMVROTATEBRKT allows mounting with rear-facing outlets

TAA-CompliantCompliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

OVERVIEW

UPC Code

037332204462

PDU Type

Switched

INPUT

PDU Input Voltage

100; 120; 127

Recommended Electrical Service

30A 120V

Maximum Input Amps

30

Maximum Input Amps Details

Agency de-rated to 24A continuous

PDU Plug Type

NEMA L5-30P

Input Phase

Single-Phase

Input Cord Length (ft.)

10

Input Cord Length (m)

3.05

OUTPUT

Output Capacity Details

3.05kW (127V), 2.88kW (120V), 2.4kW (100V) / 30A total capacity (Agency de-rated 24A); 20A max per breakered

load bank; 16A max per outlet

Frequency Compatibility

50 / 60 Hz

Output Receptacles

(24) 5-15/20R

Output Nominal Voltage

100; 120; 127

Overload Protection

Two 20A breakers protect 12 outlets each
