2.9kW Single-Phase Switched PDU with LX

Platform Interface, 120V Outlets (24 5-15/20R), 10

ft. Cord with L5-30P, 0U, TAA

MODEL NUMBER: PDUMV30NETLX

2.9kW vertical PDU distributes, monitors and manages single-phase power in an IT or industrial

environment. Built-in network interface helps you remotely monitor load levels to prevent overloads that

cause downtime.

Description

The PDUMV30NETLX 2.9kW Single-Phase Switched PDU provides advanced network control and

remote power monitoring with the ability to turn on, turn off, reboot or lock out power to each outlet.

Recommended for any IT or industrial application, it features 24 switched NEMA 5-15/20R outlets with

included cord retention brackets to prevent cables from becoming accidentally disconnected. A 10-foot

cord with NEMA L5-30P plug connects the PDU to a compatible AC power source, generator or protected

UPS.

The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU

status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports

10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2

modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported

include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.

A digital ammeter allows you to monitor each bank’s load in real time to ensure it remains well below

maximum capacity with no danger of overload. The vertical PDU mounts in 0U of space in EIA-standard

19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets. Use

the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or

equipment access.

Features

Distributes Network-Grade Single-Phase Power2.9kW 120V switched PDURecommended for network

applications requiring individual outlet control, load shedding and remote monitoring of critical network

Highlights

2.9kW 120V switched PDU

q

24 individually controllable

NEMA 5-15/20R outlets

q

Built-in LX Platform interface for

24/7 remote access

q

Digital ammeter for on-site load

monitoring in real time

q

NEMA L5-30P input with 10 ft.

AC power cord

q

To enable the Auto Probe

feature, this product requires LX

firmware update 15.5.2 or later

to be installed

q

Package Includes

PDUMV30NETLX 2.9kW Single-

Phase Switched PDU

q

Built-in LX Platform interface

q

Configuration cable

q

(24) Cable ties

q

(2) Cord retention brackets

q

Rack-mounting hardware

q

PDUMVROTATEBRKT

mounting bracket accessory

q

Owner’s manual

q
