Ordering Information

Part Number

CPU

Memory

Flash

HDMI

LAN

Serial Port

USB Host

SD

Operating

Temperature

EPC-R4680CQ-XAA1E

Rockchip RK3288

Quad Core 1.6GHz

2GB

8GB

1

1

1 x 4-wire RS-232/485

1 x 2-wire RS-232/Debug port

4 x 4-wire RS-232

5 x USB Host

1 x USB OTG

1

0 ~ 55 °C

EPC-R4680

Packing List

Part Number

Description

EPC-R4680

EPC-R4680 Box computer

Dimensions

Unit: mm

Optional Accessories

Port Number

Description

96PSA-A36W12W7

ADP A/D 100-240V 36W 12V WO/PFC

170203183C

Power cord 3P Europe (WS-010+WS-083) 183 cm

170203180A

Power cord 3P UK 2.5A/3A 250 V 1.83 M

1700019146

Power Cord CCC 3P 10A 250V 183cm

EWM-W167M201E

802.11b/g/n (1R1T)+BT4.0 WLAN and BT combo module

1750008800-01

Antenna Cable R/P SMA (M) to MHF4, 100mm

1750008671-01

Dipole Ant.SMA/M-R 2.4/5G 2.5/4dBi BLK 109mm

968AD00081*

Qucetel EC20CEFA Mini-PCIe 4G module for China

1750006264

Antenna cable SMA(F)/MHF 15cm

1750007990-01

Antenna 4G/LTE full band L=11 cm 50 Ohm

SQF-MSDM1-8G-21C SQF MICRO SD C10 MLC 8G (-25 ~ 85 °C)

* Please contat us to get suitiable celluar module for your region.

190

190

190

220

2.6

2.6

43

43

205

220
