ADF4252

Data Sheet

Rev. E | Page 6 of 30

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted.

Table 3.

Parameter1

Rating

VDD1, VDD2, VDD3, DVDD to GND2

−0.3 V to +4 V

REFIN, RFINA, RFINB to GND

−0.3 V to VDD + 0.3 V

RFINA to RFINB

±600 mV

VP1, VP2 to GND

−0.3 V to +5.8 V

VP1, VP2 to VDD1

−3.3 V to +3.5 V

Digital Input/Output Voltage to GND

−0.3 V to VDD + 0.3 V

Analog Input/Output Voltage to GND

−0.3 V to VDD + 0.3 V

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Maximum Junction Temperature

150°C

LFCSP θJA Thermal Impedance

122°C/W

Reflow Soldering

Peak Temperature

260°C

Time at Peak Temperature

40 sec

1 This device is a high performance RF integrated circuit with an ESD rating of

<2 kΩ, and it is ESD sensitive. Proper precautions must be taken for handling

and assembly.

2 GND is CPGND1, AGND1, DGND, AGND2, and CPGND2.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION
