1 / 2 page  Fanless Embedded Box PCs Features ARK-10 A4 Intel® Celeron Quad Core J1900 Quad Core SoC with Dual GbE and Dual COM Fanless Box PC Intel® Celeron J1900 Quad Core 2.0 GHz SoC 2G DDR3L Memory & 500G 2.5" 24x7 SATA HDD Built In 2 x GbE for Multiple Internet Transmission 2 x RS-232/422/485 (BIOS selection) 1 x Full-Size MiniPCIe (ex. WLAN or WWAN module) #1 Optional VESA / DIN Rail / Wall Mounting kits Threaded DC jack design Supports WISE-PaaS DeviceOn and Embedded Software APIs Specifications ARK-10-U0A4 Processor System CPU Intel® Celeron Processor J1900 Quad Core SoC Frequency 2.0 GHz (Up to 2.41 GHz w/ burst frequency enabled) L2 Cache 2 MB BIOS AMI EFI 64 Mbit (Default BIOS is supported for 64-bit OS installation, BIOS for 32-bit OS is supported by project) Memory Technology DDR3L 1333 MHz Socket 1 x 204-pin SO-DIMM, 2 GB Memory Built In Graphics Chipset Intel® Atom SoC integrated Graphic Engine DirectX* 11.1, OGL 3.0, OCL 1.1, OGL ES 2.0 Encode: H264, MPEG2/4, VC1, WMV9 Decode: H264, MPEG2 VGA 1 x VGA, support up to 1920 x 1200 at 60Hz Audio Main System ALC-888S, High Definition Audio. Line-out & Line-in Ethernet LAN #1 10/100/1000 Mbps Intel I210 GbE, support Wake on LAN LAN #2 10/100/1000 Mbps Intel I210 GbE, support Wake on LAN I/O Interface Serial Ports 2 x RS-232/422/485 (BIOS selectable) USB Interface 2 x USB 2.0 & 1 x USB3.0 Other Watchdog timer 255-level timer interval, setup by software Expansion Mini PCIe 1 x Full-size Mini PCIe, support WLAN or WWAN module #1 Storage 2.5" Drive Bay 1 x 500GB 2.5" 24x7 SATA HDD Built In mSATA 1x half-size mSATA (Suggest to assembly by CTOS or T-Part due to complex installation) Software Support Microsoft Windows Windows 10 Linux Support (by Project) Power Requirement Power Input Voltage Single 12 VDC Power Adapter AC to DC, DC12 V/3 A, 36 W with threaded design Mechanical Construction Aluminum housing Mounting VESA/DIN Rail/Wall Mounting Kits (Optional) Dimensions (W x H x D) 133.8 x 43.1 x 94.2 mm (5.27" x 1.7" x 3.71") Environment Operating Temperature 0 ~ 50° C with 0.7m/s air flow Storage Temperature -40 ~ 85 °C (-40~185 °F) Relative Humidity 95% @ 40 °C (non-condensing) Vibration During Operation 0.5Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis Shock During Operation 10G, IEC 60068-2-27, half sine, 11 ms duration Regulation EMC CE/FCC Class A, CCC, BSMI, UKCA Safety UL, CCC, BSMI, CB, UKCA #1 Mini PCIe is hardware interface for wireless communication integration only. System level RF certification is not available. RoHS COMPLIANT 2002/95/EC All product specifications are subject to change without notice. Last updated: 8-Sep-2022 |
