MEGA BRIGHT LED

BTL-54NRC-XX-X

Symbol

Parameter

Max.

Unit

Power Rating

100

mW

5

V

Continuous Forward Current

30

mA

Peak Forward Current (0.1 duty cycle @

1kHz)

50

mA

Operating Temperature Range

–35 ~ + 80

℃

Storage Temperature Range

–40 ~ + 100

℃

Lead Soldering Temperature [1.6mm (0.063inch) from body]

260℃ - max 5 seconds

Wavelength and Brightness Selection

BTL-54NRC-XX-X

Page 2 of 3

Wavelength Bin Selection

Brightness Bin Selection

Bin

Normal Red (nm)

O1

620~625

O2

625~630

O3

630~635

XX

620~635

Bin

Range(mcd)

P

1485~1930

Q

1930~2510

R

2510~3265

Packaging Options

Standard: 1000 pc bulk pack

Optional: Tape and Reel (Please specify when order)
