 12 / 20 page
background image
AD8655/AD8656
Rev. A | Page 12 of 20
35
30
25
20
15
10
5
0
0
50
100
150
200
250
300
350
CAPACITANCE (pF)
VS = ±1.35V
VIN = 200mV
–OS
+OS
T
2
VS = ±1.35V
G = +1
CL = 50pF
VIN
VOUT
20
μs/DIV
Figure 44. Small Signal Overshoot vs. Load Capacitance
Figure 41. No Phase Reversal
400ns/DIV
T
1
2
VS = ±1.35V
VIN = 200mV
GAIN = –10
RECOVERY TIME = 180ns
200mV
0V
0V
–1.35V
VIN
VOUT
T
2
VS = ±1.35V
CL = 50pF
GAIN = +1
TIME (10
μs/DIV)
Figure 42. Large Signal Response
Figure 45. Negative Overload Recovery Time
T
1
2
VS = ±1.35V
VIN = 200mV
GAIN = –10
RECOVERY TIME = 200ns
0V
–200mV
1.35V
0V
400ns/DIV
VIN
VOUT
2
T
VS = ±1.35V
CL = 100pF
GAIN = +1
TIME (1
μs/DIV)
Figure 43. Small Signal Response
Figure 46. Positive Overload Recovery Time
