SPECIFICATION AND PERFORMANCE

SERIES:

104D-TCA0-R06

FILE:

104D-TCA0-R06_spec

DATE:

2014/01/09

The information contained herein is exclusive property of. Do not copy and print except that Attend accepts.

本文件係屬立威科技股份有限公司所有；非經同意，不得以任何覆寫、拷貝、翻印等方式私自據有。亦不得擅加毀損、塗改。

-2 -

SHELL OR COVER

Material Shell :SUS304R-3/4 H

Latch : SUS304R-3/4 H

Spring : Piano Wire

Drag Link : SUS304

Plating

RATING

Rating Current: 0.5A (Max.)/(1PIN)

Rating Voltage: 100V AC/DC

Operating Temperature: -25℃ to +90℃

Storage Temperature: -40℃ to +90℃

ELECTRICAL

Item

Requirement

Test Condition

Contact Resistance

Initial: 80 mΩ (Max) Solder connectors on PCB and mate them

together, measure by applying closed circuit

current of 10mA maximum at open circuit

voltage of 20mV (max).

(JIS C5402 5.4)

Insulation Resistance Initial:

1,000MΩ(Min).

Apply 500V DC between adjacent contacts,

or contact and ground.

(MIL-STD-202 METHOD 302)

Dielectric

Withstanding Voltage

No breakdown

Mate connectors; apply 500V AC(rms.)

between two adjacent for 1minute.

(Trip current:1mA)

(MIL-STD-202 METHOD 301)

MECHANICAL

Item

Requirement

Test Condition

Contact Retention

Force

2.5N per pin (Min.)

Place a connector on the push-pull machine,

then apply a force on a contact head and

push the contact to the opposite direction of

the contact insertion at the speed of

25 ± 3mm/min. (EIA364-29)
