Data Sheet S15535EJ3V0DS
27
µPD720100A
3.
PACKAGE DRAWING
S
S
N
J
detail of lead end
R
K
M
L
P
I
S
Q
G
F
M
H
160-PIN PLASTIC LQFP (FINE PITCH) (24x24)
NOTE
Each lead centerline is located within 0.10 mm of
its true position (T.P.) at maximum material condition.
ITEM
MILLIMETERS
A
B
D
G
26.0
±0.2
24.0
±0.2
0.5 (T.P.)
2.25
J
26.0
±0.2
K
C
24.0
±0.2
I
0.10
1.0
±0.2
L
0.5
±0.2
F
2.25
N
P
Q
0.10
1.4
±0.1
0.125
±0.075
S160GM-50-8ED-3
S
1.7 MAX.
H
0.22+0.05
−0.04
M
0.145+0.055
−0.045
R3
°+7°
−3°
120
121
160
140
41
80
81
A
B
CD
