19 4-wire Serial Configuration Interface

CC2400 is configured via a simple 4-wire

SPI-compatible interface (SI, SO, SCLK

and CSn) where

CC2400 is the slave. This

interface is also used as data interface in

buffered mode (see page 27).

There are 44 16-bit configuration registers,

9 Command Strobe Registers, and one

has a 7-bit address. The FIFO (32 bytes)

is 8 bits wide. A Read/Write bit indicates a

read or a write operation and forms the 8-

bit address field together with the 7-bit

address.

Some registers are termed Command

Strobe

Registers.

addressing

Command

Strobe

internal

sequences

will

started.

These

commands can be used to quickly change

from RX mode to TX mode, for example.

A full configuration of

CC2400 requires

sending 44 data frames of 24 bits each (7

address bits, R/W bit and 16 data bits).

The time needed for a full configuration

depend on the SCLK frequency. With a

SCLK frequency of 20 MHz the full

configuration is done in less than 5

µs.

Setting the device in power down mode

requires addressing one command strobe

than 0.4

µs. All registers except the strobe

registers are also readable.

In each write-cycle, 24 bits are sent on the

SI-line. The bit to be sent first is the R/W

bit (0 for write, 1 for read). The next seven

bits are the address-bits (A6:0). A6 is the

MSB (Most Significant Bit) of the address

and is sent first. The 16 data-bits are then

transferred (D15:0). During address and

data transfer the CSn (Chip Select, active

low) must be kept low. See Figure 6.

The timing for the programming is shown

in Figure 6 with reference to Table 12. The

clocking of the data on SI into the

CC2400

is performed on the positive edge of

SCLK.

The data word is loaded into the internal

configuration register, when the last bit,

D0, of the 16 data bits has been written.

The configuration data will be retained

during a programmed power-down mode,

but not when the power-supply is turned

off. The registers can be programmed in

any order.

The configuration registers can also be

read by the microcontroller via the same

configuration interface. The R/W bit must

be set high to initiate the data read-back,

then the seven address bits are sent.

CC2400 then returns the data from the

addressed register. SO is used as the

data output and must be configured as an

input by the microcontroller.

The command strobe register is accessed

in the same way as for a write operation,

but no data is transferred. That is, only the

R/W bit and the seven address bits are

written before CSn should be set high.

Figure 7 shows a summary of read and

write operations. A register read/write can

be terminated after one byte if only the

most significant byte is required. A register

can also be accessed repeatedly without

writing the address again. The buffer FIFO

(8 bit wide, 32 bytes) can be written

continuously by simply writing new bytes

over and over. The internal data pointer is

then updated for every written byte. The

session is terminated when the CSn is set

high.

Please note that a longer hold time, tps, is

needed before setting CSn high when

accessing the FIFO in buffered mode.

During the transfer of the address, the

CC2400 returns a status byte on the SO

line containing some important flags. This

is shown in Table 13.
