15.2.1

Controller Interrupt Sources

There are four controller interrupt sources which can be enabled separately in USBIEN:

•

SPINT: Suspend Interrupt Flag.

This flag triggers an interrupt when a USB Suspend (Idle bus for three frame periods: a J

state for 3 ms) is detected.

•

SOFINT: Start Of Frame Interrupt Flag.

This flag triggers an interrupt when a USB start of frame packet has been received.

•

EORINT: End Of Reset Interrupt Flag.

This flag triggers an interrupt when a End Of Reset has been detected by the USB

controller.

•

WUPCPU: Wake Up CPU Interrupt Flag.

This flag triggers an interrupt when the USB controller is in SUSPEND state and is re-

activated by a non-idle signal from USB line.

15.2.2

Endpoint Interrupt Sources

Each endpoint supports four interrupt sources reported in UEPSTAX and combined together to

appear as a single endpoint interrupt source in UEPINT. Each endpoint interrupt can be enabled

separately in UEPIEN.

•

TXCMP: Transmitted In Data Interrupt Flag.

This flag triggers an interrupt after an IN packet has been transmitted for Isochronous

endpoints or after it has been accepted (ACK’ed) by the host for Control, Bulk and Interrupt

endpoints.

•

RXOUT: Received Out Data Interrupt Flag.

This flag triggers an interrupt after a new packet has been received.

•

RXSETUP: Receive Setup Interrupt Flag.

This flag triggers an interrupt when a valid SETUP packet has been received from the host.

•

STLCRC: Stall Sent Interrupt Flag/CRC Error Interrupt Flag.

This flag triggers an interrupt after a STALL handshake has been sent on the bus, for

Control, Bulk and Interrupt endpoints.

This flag triggers an interrupt when the last data received is corrupted for Isochronous

endpoints.
