V200Z-R
FN-LINK TECHNOLOGY LIMITED
19
9. The Key Material List
Chipset
BES2600, BGA-169L, 6.6x6.8mm, Pitch 0.5mm
Bestechnic
PCB
V200Z-R, 28X20X0.8mm, 4L HDI, Matte black
Brain-power, KX-PCB, SL-PCB, Sunlord
Crystal
3225, 24MHz, 10ppm
TST,HOSONIC,TKD,ECEC,JWT
Inductor
2520, 2.2uH ,±20%
Sunlord, Cenke, Ceaiya, Microgate
Shielding
V200Z-R, Shielding cover, 18.5x18.6x1.7mm, T=0.2mm
Suntech, JLT
10. Recommended Reflow Profile
Referred to IPC/JEDEC standard.
Peak Temperature : <260°C
Number of Times : 2 times
