ISL73041SEH Datasheet

3.

Specifications

3.1

Absolute Maximum Ratings

Caution: Do not operate at or near the maximum ratings listed for extended periods of time. Exposure to such

conditions can adversely impact product reliability and result in failures not covered by warranty.

3.2

Thermal Information

Parameter

Minimum

Maximum

Unit

PVCC to PGND; BOOT to PHS

-0.3

+6.5

V

VDD to SGND

-0.3

+20

V

SGND to PGND

-0.3

+0.3

V

PHS to PGND

-0.3V DC

+20

V

PHS to PGND[1]

1. Tested in a heavy ion environment at LET = 67MeV•cm2/mg at 125°C.

-

+16.5

V

PHS to PGND[2]

2. Tested in a heavy ion environment at LET = 86MeV•cm2/mg at 125°C.

-

+13.5

V

PHS to PGND (repetitive transient)

-5V (100ns)

-

V

BOOT to PGND

-0.3

+24

V

BOOT to PGND[1]

-

+21.5

V

BOOT to PGND[2]

-

+18.5

V

EN to SGND

-0.3

VDD+0.3

V

AVCC, FB, PWM, FLT, RDU, RDL to SGND

-0.3

+6.5

V

UGH, UGL

PHS-0.3

BOOT+0.3

V

LGH, LGL

GND-0.3

PVCC+0.3

V

Human Body Model (Tested per MIL-STD-883 TM3015.7)

-

5

kV

Charged Device Model (Tested per JS-002-2018)

-

1

kV

Latch-Up (Tested per JESD78E; Class 2, Level A)

-

±100

mA

Parameter

Package

Symbol

Conditions

Typical

Value

Unit

Thermal Resistance

16 Pad CLCC Package

θJA[1]

1. θJA is measured in free air with the component mounted on a high-effective thermal conductivity test board with direct attach features.

See TB379.

Junction to air.

37

°C/W

θJC[2]

2. For θJC, the case temp location is the center of the package underside.

Junction to case.

6.5

°C/W

Parameter

Minimum

Maximum

Unit

Maximum Junction Temperature

-

+150

°C

Storage Temperature Range

-65

+150

°C
