ITEM

SYMBOL

VALUE

Input

Continuos LED Current

IF

50 mA

Peak LED Current (f=100 Hz, duty=1%)

IFP

500 mA

LED Reverse Voltage

VR

5 V

Input Power Dissipation

PIn

75 mW

Output

Load Voltage

VL

1500 V (AC peak or DC)

Load Current (A)

IL

A

45 mA (AC or DC)

B

50 mA (DC)

C

70 mA (DC)

Peak Load Current (1 ms, 1 shot) (A)

IPeak

200 mA

Output Power Dissipation (mW)

POut

450 mW

Total Power Dissipation (mW)

PT

500 mW

I/O Breakdown Voltage

VI/O

3750 Vrms

Operating Temperature

TOpr

-40

°C to +85°C

Storage Temperature

TStg

-40

°C to +100°C

ITEM

SYMBOL

MIN

TYP

MAX

UNITS

CONDITIONS

Input

LED Forward Voltage

VF

1.0

1.17

1.5

V

IF = 10mA

Operation LED Current

IF On

0.9

5.0

mA

Recovery LED Voltage

VF Off

0.5

1.0

V

Output

On-Resistance Drain to Drain

ROn

110

200

Ω

IF = 10mA

IL = Rating (within 1 sec.)

180

300

Ω

IF = 10mA, IL = <5mA

Off-State Leakage Current

ILeak

10

μA

IF = 0mA, VL = 1500V

Output Capacitance

COut

83

pF

VL= 0V, f = 1MHz

Transmission

Turn-On Time

TOn

0.3

1.0

ms

IF = 10mA, IL = Rating

Turn-Off Time

TOff

0.05

0.5

ms

Coupled

I/O Insulation Resistance

RI/O

1010

Ω

I/O Capacitance

CI/O

1.3

pF

f = 1MHz

ABSOLUTE MAXIMUM RATINGS (Ambient Temperature: 25˚C)

ELECTRICAL SPECIFICATIONS LED (Ambient Temperature: 25˚C)

Part Number: 40 Series

High Voltage - 1 Form A - PhotoDMOS Relays

Product Data Sheet

Relays

1500 VOLTS
