Part Number: 74 Series

General Purpose - 1 Form B / 2 Form B - PhotoDMOS Relays

Product Data Sheet

SCHEMATIC

ORDERING INFORMATION

FEATURES


Phone: (1) 973 777 6900

www.comus-intl.com

Fax: (1) 973 777 8405

As part of the company policy of continued product improvement, specifications may change without notice. Our sales office will be pleased to help you with the latest information on this product range and

the details of our full design and manufacturing service. All products are supplied to our standard conditions of sale unless otherwise agreed in writing.

An ISO 9001 Certified Company

Belgium: + 32 (0)12 390400 - Comus Europe Ltd (Assemtech) UK: +44 (0) 1255 862236 - Germany: +49 (0)911 923 15 943 - Netherlands: +31(0)45 54 39 345 - India: +(91) (44) 43219090

©2016 Copyright Comus International, 454 Allwood Road, Clifton NJ 07012, USA

Relays

•

PhotoDMOS Relays

• 400 Volt, 90 mA

• On-Resistance: 28 Ω (typical)

• I/O Breakdown Voltage: 1500 Vrms Min.

• Max LED Current 3.0 mA

• Low Off-State Leakage Current 10 μ A Max

1: Anode

2: Cathode

3: NC

4, 6: Drain

5: Source

1: Anode

2: Cathode

3, 4: Drain

1, 3: Anode

2, 4: Cathode

5, 6, 7, 8: Drain

(LED)

(LED)

(MOS FET)

(MOS FET)

(LED)

(LED)

(MOS FET)

(LED)

(LED)

(MOS FET)

SOP4

SOP8

SMD4

DIP4

DIP6

4.4

4.4

6.4

6.4

6.4

6.4

6.4

2.0

2.0

3.4

3.4

3.4

3.4

3.4

4.3

9.4

4.7

8.8

4.7

8.8

9.8

3.4

6.4

9.8

SMD6

SMD8

DIP8

(+)

(-)

(+)

(-) (+) (-)

(+) (-)

4

3

6 5 4

1 2 3

1

2

3

4

8

7

6

5

1

2

Drawings not to scale. All dimensions in mm nominal. Pitch: 2.54 mm

F = SMD

S = SOP

R1 = Tape & Reel (SMD / SOP Only)

Part Number Example: XX74X-XX

AH74F-R1 = Series 74, 2 Form B, 8 Pin, SMD with tape and reel

packaging

AG74(F)(S)

AH74(F)(S)

AE74(F)

400 VOLTS

Rev: 0 - Date: June/17/2016 - Signature: BR

74

AG = 4 pin

AE = 6 pin

AH = 8 pin

Body Style Series Options

Form B
