Relays

ITEM

SYMBOL

VALUE

OUTLINE PACKAGE

SOP 4/8

DIP 4/8

SMD 4/8

DIP 6

SMD 6

1CH

2CH

1CH

2CH

1CH

Input

Continuos LED Current

IF

50 mA

Peak LED Current (f=100 Hz, duty=1%)

IFP

500 mA

LED Reverse Voltage

VR

5 V

Input Power Dissipation

PIn

75 mW

Output

Load Voltage

VL

400 V (AC peak or DC)

Load Current (mA)

IL

70

60

90

80

90

Peak Load Current (1 ms, 1 shot) (mA)

IPeak

400

400

400

400

400

Output Power Dissipation (mW)

POut

300

450

450

600

450

Total Power Dissipation (mW)

PT

350

500

500

650

500

I/O Breakdown Voltage (Vrms)

VI/O

1500

1500

1500

1500

1500

Operating Temperature

TOpr

-40˚ +85˚C

Storage Temperature

TStg

-40˚ +100˚C

ITEM

SYMBOL

MIN

TYP

MAX

UNITS

CONDITIONS

Input

LED Forward Voltage

VF

1.0

1.17

1.5

V

IF = 10mA

Operation LED Current

IF Op

0.9

3.0

mA

Recovery LED Voltage

VF Rec

0.5

1.0

V

Output

On-Resistance Drain to Drain

ROn

28

35

Ω

IF = 0mA

IL = Rating Time to flow is

within 1 sec.

Off-State Leakage Current

ILeak

10

μA

IF = 10mA, VL= 400V

Output Capacitance

COut

165

pF

IF = 10mA, VL= 0V, f= 1MHz

Transmission

Operate Time

TOff

0.1

2.0

ms

IF = 5mA

IL = Rating

(for SOP type)

Release Time

TOn

0.05

0.5

ms

Operate Time

TOff

0.15

2.0

ms

IF = 10mA

IL = Rating

(for DIP/SMD type)

Release Time

TOn

0.05

0.5

ms

Coupled

I/O Insulation Resistance

RI/O

109

Ω

I/O Capacitance

CI/O

1.3

pF

f = 1MHz

ABSOLUTE MAXIMUM RATINGS (Ambient Temperature: 25˚C)

Part Number: 74 Series

General Purpose - 1 Form B / 2 Form B - PhotoDMOS Relays

Product Data Sheet

Rev: 0 - Date: June/17/2016 - Signature: BR

ELECTRICAL SPECIFICATIONS (Ambient Temperature: 25˚C)

400 VOLTS

Form B
