AD8531/AD8532/AD8534
Rev. F | Page 10 of 20
10
0%
100
90
500ns
500mV
VS = ±2.5V
AV = 1
RL = 2kΩ
TA = 25°C
SUPPLY VOLTAGE (±V)
0.7
0.8
0.6
0.5
0.4
0.3
0.2
0.1
0
0.75
1.50
1.00
2.00
2.50
3.00
TA = 25°C
Figure 33. Large Signal Transient Response
Figure 30. Supply Current per Amplifier vs. Supply Voltage
10
0%
100
90
500ns
500mV
VS = ±1.35V
AV = 1
RL = 2kΩ
TA = 25°C
500 ns/DIV
0V
VS = 1.35V
VIN = 50mV
AV = 1Ω
RL = 2kΩ
CL = 300pF
TA = 25°C
Figure 34. Large Signal Transient Response
Figure 31. Small Signal Transient Response
10
0%
100
90
10µs
1V
1V
500ns/DIV
0V
VS = 2.5V
VIN = 50mV
AV = 1Ω
RL = 2kΩ
CL = 300pF
TA = 25°C
Figure 35. No Phase Reversal
Figure 32. Small Signal Transient Response
