ES-346 Ethernet 4 Port RS422/485

Port Settings - Ethernet

Data Rate

10/100 Mega bits/second

Cabling

Normal / Crossover auto-sensing (Auto-MDIX)

Software

Network Protocols

ICMP, IP, TCP, DHCP, BOOTP, Telnet, HTTP, RFC2217

Configuration Options

Windows Utility, Web Interface

OS Compatibility

Microsoft Windows 7 32 bit 64 bit Editions / Windows Server 2008 32 bit 64 bit Editions / Windows Vista

32 bit 64 bit Editions / Windows XP 32 bit 64 bit Editions / Microsoft Windows 2000 / /Fully RFC2217

compliant / Interface for other OS’s & Linux

Connection to Network

Ethernet 10BaseT / 100BaseTX

Port Settings - RS422/485

Baud Rate

From 110 - 1,000,000 1 MegaBaud

Data Bits

5,6,7 or 8

Parity

Odd, Even, None, Mark or Space

Stop Bits

1, 1.5 or 2

Flow Control

RTS/CTS, XON/XOFF

Tx/Rx Modes

RS422 Standard: RS422 allows one transmitter and up to 10 receivers with data transmitter rates up to 10

megabits per second for distances up to 40 feet and up to 100 Kilobits per second for distances up to 4,000

feet (1219 metres).

To achieve good long distance noise immunity, 2 wires are used to carry each signal, configured as a twisted

pair of cables. The TXD pair and RXD pair are used to carry the data whilst the RTS pair and CTS pair lines are

used for handshaking. Thus 2 twisted pairs are used without handshaking and 4 twisted pair cable is used with

handshaking both these schemes allow full duplex data communications.

RS485 Standard: RS485, based on the RS422 standard allows up to 32 driver/receivers pairs on a standard

load or 128 low load devices per port can be connected. Whilst only one of these should be transmitting data

at any time, the rest can all simultaneously listen to the data. Handshaking is performed by software protocol.

Two twisted pairs form a full duplex system.

Often only one twisted pair cable is used as the TXD and RXD lines are tied together; this is known as

half duplex mode. Brainboxes RS422/485 products implement a state of the art hardware autogating circuit

ensuring error free communications in half duplex configurations.

Environmental

Operating Temperature

0 to 55

oc

Storage Temperature

-20 to 85

oc

Ambient Relative Humidity

5 to 95% (non-condensing)

Housing

IP-30 rated case

Approvals

Industry Approvals

AEO C-TPAT Microsoft Certified Gold Partner WEEE RoHS EMC: CE TAA

Microsoft Approvals

Microsoft Certified Gold Partner

Microsoft Signed Drivers

Windows 7 32 bit 64 bit Editions
