ES-346 ETHERNET TO SERIAL DEVICE SERVER

Ethernet 4 Port RS422/485

CONNECT, CONFIGURE, CONTROL YOUR SERIAL DEVICES

Description

Ethernet to Serial device server providing access to four RS422/485 serial ports. Data transfer rates up to 1,000,000 baud rates, coupled with

1Mbit/s line drivers deliver uncompromising performance. Our ES range provides simple instant networked serial ports. RS485 - 1 twisted pair

- half duplex configuration with autogating provides trouble free data transmission due to automatic control of data direction. A web interface

allows secure configuration and control of the serial ports over a local network or the internet using any browser. For Windows our in-house

designed 32 bit and 64 bit driver gives you local COM ports, retaining existing software applications and allowing you to connect across your

network to remote devices just as if they were attached locally. You can access the device via TCP/IP sockets from any networked device like

an Android tablet, PC or phone. Serial Port Tunnelling individually configurable allows serial cable replacement over any distance, no software

required. On Windows OS TCP/IP sockets are handled by the Winsock API, this will differ on other OSs.

Windows Users - Our software drivers gives you local COM ports, allowing you to retain your existing software applications and connect to your

devices over the network. COM Port can be assigned from COM1 to COM255 and the Brainboxes Ethernet to serial device remembers your COM

Port assignment on reboots.

Web Interface Users (Linux/Apple OS/Android) - Alternatively access the device via TCP/IP socket from any networked device. Configure options

via web interface.

Extend your reach! Remote serial devices with local control. With Brainboxes industry renowned Lifetime Warranty and Lifetime Support!

Example Application

Features

l

4 port RS422/485

l

Max baud rate 1,000,000 1 MegaBaud

l

10/100Base TX Ethernet port

l

User friendly interface, simple to use, powerful in operation

l

Web configuration and RFC2217 compliant interface

l

IP-30 rated enclosure

l

LED status indication

l

Optional DIN rail mounting kit

l

Serial Port Tunneling (individually configurable) allows serial cable

replacement over any distance, no software required

l

Power supply included with screw fix connector (5-30V DC)

l

Simple operation for each and every operating system!

l

Lifetime Warranty

l

Lifetime Support

ES-346

Stepper Motor Control

Server
