Eletrical Characteristics

Symbol

Description

VRWM

Rated reverse stand-off voltage

VBR

Minimum breakdown voltage @IT = 1mA

VCL

Clamping voltage

IPP

Maximum peak pulse current

Reverse leakage current @VRWM

Typical line capacitance (VIO=0V, VP-P = 30mV, f = 1MHz)

Table-4

Parameters Description

At TA = 25

℃ unless otherwise noted

Part Number

VRWM

(max.)

VBR

(min.)

VCL@I=1A

(max.)

IPP

(max.)

VCL@I=IPP

(max.)

(typ.)

(V)

(A)

(V)

(uA)

(pF)

ALD03CU

3.3

4.0

8.5

17.0

1.0

0.8

ALD05CU

5.0

6.0

9.5

15.0

1.0

0.8

ALD08CU

8.0

8.5

12.0

1.0

0.8

ALD12CU

12.0

13.3

19.0

7.0

1.0

0.8

ALD15CU

15.0

16.5

24.0

5.0

1.0

0.8

ALD24CU

24.0

26.0

34.0

4.0

1.0

0.8

Table-5 Electrical Characteristics for All Series

ALDxxCU series

www.shunyegroup.com.cn

V2.22

ALD24CU 数据表(PDF) 3 Page - Shanghai Shunye Electronics Co.,Ltd.
