Ordering Information

THERMATTACH® Thermally Conductive Attachment Tapes

Sheets form, roll form, or die-cut parts. Offered on continuous rolls.

A general ordering information table is included below for reference.

Part Number:

These attachment tapes are available in the following formats.

Contact Chomerics for custom widths, part sizes, etc.

W = 0 (Standard Part)

XX = 13 for PSA two sides YYYY = 4 digit alpha/numeric part number.

Contact Chomerics.

Material Type

ZZZZ =

T405

T405-R

T411

T412

T418

W = 7 (Roll of material) XX = 10 (100 foot roll)

XX = 40 (400 foot roll)

YYYY = 0750 for 7.5” wide

YYYY = 1150 for 11.5” wide

YYYY = 2400 for 24” wide

For T404/T414 Only:

YYYY= 0600 for 6”wide

YYYY= 0900 for 9” wide

YYYY= 1900 for 19” wide*

W = 9 (Custom part)

XX = 13 for PSA two sides YYYYY = Custom Part Number.

Contact Chomerics

6W

XX

YYYY

ZZZZ

Handling Information

These products are defined by

Chomerics as “articles” according

to the following generally

recognized regulatory definition for

articles:

An article is a manufactured item

“formed to a specific shape or

design during manufacturing,”

which has “end use functions”

dependent upon its size and shape

during end use and which has

generally “no change of chemical

composition during its end use.”

In addition:

• There is no known or anticipated

exposure to hazardous

materials/substances during

routine and anticipated use of

the product.

• The product’s shape, surface,

and design is more relevant than

its chemical composition.

These materials are not deemed by

Chomerics to require an MSDS. For

further questions, please contact

Chomerics at 781-935-4850.

* for T404/T414 only

Rolls of width

greater than 12”

are not available

with embossment

( )
