This AOS product reliability report summarizes the qualification result for AOZ8000CI.

Review of the electrical test results confirm that AOZ8000CI pass AOS quality and reliability

requirements for product release. The continuous qualification testing and reliability monitoring

program ensure that all outgoing products will continue to meet AOS quality and reliability standards.

Table of Contents:

I.

Product Description

II.

Package and Die information

III.

Qualification Test Requirements

IV.

Qualification Tests Result

V.

Reliability Evaluation

VI.

Quality Assurance Information

I. Product Description:

The AOZ8000CI is a transient voltage suppressor array designed to protect high speed data lines from ESD and

lightning. The product comes in RoHS compliant, SOT-23 package and is rated over a -40°C to +85°C ambient

temperature range.

.

Absolute Maximum Ratings

Parameter

VP-VN

6V

Peak Pulse Current (Ipp), tp=8/20uS

5A

-65°C to +150°C

ESD Rating per IEC61000-4-2, contact

(1)

±12kV

ESD Rating per IEC61000-4-2, air

(2)

±15kV

ESD Rating per Human Body Model

(2)

±15kV

-40°C to +125°C

Notes:

II. Package and Die Information:

Product ID

AOZ8000CI

Process

UMC 0.5um 5/18V 2P3M process

Package Type

SOT-23

Die

UE003A3 (size: 716 x 616 um)

L/F material

Copper A194FH

Die attach material

84-3J epoxy

Die bond wire

Au, 1mil

Mold Material

MP8000CH4

Plating Material

Pure Tin
