M-34

M

Custom-color bezels and

enclosures are available

for original equipment

manufacturers.

Enhance the appearance

of your equipment design

with custom colors.

Consult the

OMEGA

® OEM

GROUP.

Custom firmware and hardware available in quantity.

CUSTOM CONFIGURATIONS

Model No.

Description

DP40-A3

Analog output

DP40-S24

Isolated RS232/RS485

communications*

Suffix

Description

-230

230 Vac power

-DC

9 to 32 Vdc isolated power

-GN

Green LED display

Power and Display Options

Model No.

Description

DP40-9SC2

9-pin serial connector for RS232

DP40-9SC4

9-pin serial connector for RS485

DP40-25SC2

25-pin serial connector for RS232

DP40-25SC4

25-pin serial connector for RS485

Accessories for Computer Communications

Model No.

Description

DP40-B

Isolated BCD output board**

DP40-R

Dual 7 A mechanical relays**

DP40-R4

Dual 7 A and dual 1 A relays**

Control/BCD Outputs

** Order DP40-B, DP40-R or DP40-R4; only 1 option can be used

per unit. DC power option not available on models with

DP40-R or DP40-R4.

Analog Output/Computer Communications

Comes complete with operator’s manual.

* Both options cannot be used at the same time in a single unit.

DP40-S24 option comes with communications cable with phone plug

termination. For proper termination to a computer, 9-pin and 25-pin

connectors are offered on this page.

To Order (Specify Model Number)

Model No.

Description

DP41-E

Process voltage/current indicator

DP41-S

Strain gage indicator

DP41-W

Weight NTEP strain indicator

DP41-TC

Thermocouple indicator

DP41-RTD

RTD indicator

DP41-U

Universal input indicator

DP41Z-E

Split-display voltage/current indicator

DP41Z-S

Split-display strain gage indicator

DP41Z-W

Split-display weight NTEP strain indicator

DP41Z-TC

Split-display thermocouple indicator

DP41Z-RTD

Split-display RTD indicator

DP41Z-U

Split-display universal input indicator

Model No.

Description

SPC4

NEMA 4 (IP65) heavy-duty

splashproof lens, screw clamp

SPC18

NEMA 4 (IP65) splashproof lens,

spring clip

DP41-TBS

Economical bench stand

DPP-5

1

⁄8 DIN panel punch

Accessories for DP41 Meters

Ordering Examples: DP41-TC-S24-A3-DC, DP41 unit for

thermocouple inputs, with 10 to 32 Vdc power, RS232

communications, analog output and DP40-9SC2, 9-pin serial

connector

DP41Z-E split meter with remote display,

panel mount or surface mount with bracket,

shown smaller than actual size.

DP41-TC, with probe, sold

separately, shown smaller than

actual size.

MOST POPULAR MODELS HIGHLIGHTED!
