Section 7 Interrupt Controller

Rev. 2.00 Sep. 24, 2008 Page 129 of 1468

REJ09B0412-0200

Section 7 Interrupt Controller

7.1

Features

• Two interrupt control modes

Any of two interrupt control modes can be set by means of bits INTM1 and INTM0 in the

interrupt control register (INTCR).

• Priority can be assigned by the interrupt priority register (IPR)

IPR provides for setting interrupt priory. Eight levels can be set for each module for all

interrupts except for the interrupt requests listed below. The following eight interrupt requests

are given priority of 8, therefore they are accepted at all times.

 NMI

 Illegal instructions

 Trace

 Trap instructions

 CPU address error

 DMA address error (occurred in the DTC, DMAC and EXDMAC)

 Sleep instruction

 UBC break interrupt

• Independent vector addresses

All interrupt sources are assigned independent vector addresses, making it unnecessary for the

source to be identified in the interrupt handling routine.

• Thirteen external interrupts

NMI is the highest-priority interrupt, and is accepted at all times. Rising edge or falling edge

detection can be selected for NMI. Falling edge, rising edge, or both edge detection, or level

sensing, can be selected for

IRQ11 to IRQ0.

• DTC, DMAC control

DTC and DMAC can be activated by means of interrupts.

• CPU priority control function

The priority levels can be assigned to the CPU, DTC, DMAC and EXDMAC. The priority

level of the CPU can be automatically assigned on an exception generation. Priority can be

given to the CPU interrupt exception handling over that of the DTC, DMAC and EXDMAC

transfer.
