Multi Layer Ferrite Inductors

Type MCL

crosstalk and provides high reliability in a wide range

of temperature and humidity ranges

■ Standard EIA packages: 1J, 2A, 2B

■ Nickel barrier with solder overcoat

for excellent solderability

■ Magnetically shielded

* Please note: KSE’s part numbers do not contain any spaces or hyphens.

3. Ordering and Specifying Information*

2. 2.1 Dimensions

1. General

Size

Tolerance

Nominal

Inductance

1J

2A

2B

K: ±10%

M: ±20%

047 = .047µH

R10 = .100µH

1J

J

R10

Packaging

TD: 7" Paper Tape

(1J - 4,000 pcs/reel; 2A - 0.047µH

- 2.2µH = 4,000 pcs/reel)

TE: 7" Embossed Plastic

(2A - 2.7µH - 10µH = 3,000

pcs/reel; 2B - 3,000 pcs/reel)

TE

Termination

Material

T: Sn

(Other termination

styles available,

contact factory

for options)

T

MCL

Type

Material

Permeability

Code:

H

J

H

CERTIFIED

CERTIFIED

L

.063±.006

(1.6±0.15)

.031±.006

(0.8±0.15)

.014±.006

(0.36±0.15)

.031±.006

(0.8±0.15)

W

t

d

1J

(0603)

.079±.008

(2.0±0.2)

.049±.008

(1.25±0.2)

.02±.01

(0.51±0.25)

.035±.008

(0.9±0.2)

2A

(0805)

.126±.008

(3.2±0.2)

.063±.008

(1.6±0.2)

.02±.01

(0.51±0.25)

.043±.008

(1.1±0.2)

2B

(1206)

Size

Code

4. Standard Applications

Part

Designation

Inductance

L (µH)

Minimum

Q

DC

Resistance

Maximum

(Ω)

Allowable

DC Current

Maximum

(mA)

L.Q. Test

Frequency

(MHz)

Self Resonant

Frequency

Typical

(MHz)

0.047

0.068

10

15

50

260

250

0.30

0.50

0.60

0.80

50

245

240

205

180

165

150

136

25

0.082

0.10

0.12

0.15

0.18

0.22

0.27

Operating

Temperature

Range

MCL1JHTTD047M

MCL1JHTTD068M

MCL1JHTTD082M

MCL1JHTTDR10*

MCL1JHTTDR12*

MCL1JHTTDR15*

MCL1JHTTDR18*

MCL1JHTTDR22*

MCL1JHTTDR27*

* Add tolerance character (K, M) - Other tolerances available upon request
