Able to transmit up to 5 CATV

channels over one multimode fiber.

Supports transmission of sub-band,

low-band, FM, mid-band, and high-

band channels, adding flexibility to

the system.

Plug-and-play design assures easy

installation.

Ideal for small corporate TV video

distribution, campus media retrieval

systems, teleconferencing applications,

or as a return path transmitter for

larger video systems.

The most comprehensive product

of its type available in the industry.

Model 2801 PRO: Stand-alone Transmitter and Receiver

CATV

Model 2801PRO

Multimode CATV Transport

The

video link

provides a high-quality system for transferring five video

channels per multimode fiber with complete EMI immunity.

The use of state-of-the-art 1300 nm LEDs and PIN detectors

allows

Model

2801

PRO

to

operate

at

exceptional

performance

levels.

The

unit

offers

excellent

analog

bandwidth that ranges from 5 to 350 MHz, allowing

transmission of all sub-band, low-band, FM, mid-band, and

high-band channels. This system also offers excellent

performance at lower channel loadings. The Model 2801 PRO

provides an inexpensive option for transmitting high-quality

video, making it an obvious choice for video delivery services

using multimode fiber.

Model 2801 PRO 5 Channel CATV VSB/AM

2801 PRO

Transmitter

2801 PRO

Receiver

RF In (5-350 MHz)

RF Out

MM

Fiber

© Copyright 2007. EMCORE Corporation

2020 Kraft Drive, Suite 1000, Blacksburg, VA 24060

USA (800) 732-5252 • TEL (540) 961-1945 • FAX (540) 961-1900

www.forceinc.com

www.emcore.com

•

Information contained herein is deemed to be reliable and accurate as of issue date. EMCORE reserves the right to change the design or specifications of

the product at any time without notice. Ortel, the Ortel logo, EMCORE, and the EMCORE logo are trademarks of EMCORE Corporation.

2801P-T-1310-ST CATV TX

MULTIMODE, 1300 nm

10-300 MHz

orce

Optical Broadcast Systems

SERIAL NUMBER

2020 Kraft Drive, Suite 1000 • Blacksburg, VA 24060

http://www.forceinc.com • Made in USA

MANUFACTURED DATE

2801P-R-ST CATV RX

MULTIMODE, 1300 nm

10-300 MHz

2020 Kraft Drive, Suite 1000 • Blacksburg, VA 24060

http://www.forceinc.com • Made in USA

orce

Optical Broadcast Systems

SERIAL NUMBER

MANUFACTURED DATE
