Min

Typ

Max

Units

Power Supply Voltage (Tx)

+9.0

+11.0

VDC

Power Supply Voltage (Rx)

+9.0

+11.0

VDC

Power Supply Current (Tx)

250

270

mA

Power Supply Current (Rx)

100

110

mA

Min

Typ

Max

Units

Weight

6

oz.

170

g

Physical Dimensions

3.75 x 2.95 x 1.12

in.

95 x 75 x 29

mm

-17

-16

-15

-14

-13

-12

-11

-10

-9

-8

-7

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

Received Optical Power (dBm)

1 Channel

3 Channels

5 Channels

CSO = -70 dBc

CTB = -55 dBc

Optical Characteristics*

Min

Typ

Max

Units

Operating Wavelength

1290

1300

1330

nm

Lower Bandwidth

2

5

Mhz

Upper Bandwidth

350

400

Mhz

Optical Output Power

-8.0

-7.0

-6.0

dBm

Optical Loss Range

0

9

dB

Impedance

75

ohms

Carrier-to-Noise Ratio

See Graph Below

Min

Typ

Max

Units

Operating Temp. Range

+10

+45

°C

Storage Temp. Range

-20

+70

°C

Relative Humidity

10

95

%

Environmental Characteristics*

Electrical Characteristics*

Physical Characteristics*

*System performance specifications indicated for use with 62.5/125

µm multimode fiber.

See IOM2801 PRO for complete performance specifications.

Contact an Applications Engineer or visit our website for complete

specifications on rack-mounting and power supply options.

MM 5 Channel Tx and Rx P/N

2801 PRO Tx and Rx Options

Std.-alone Tx, , 1300 nm, ST

Std.-alone Rx, 1300 nm, ST

5 Channels

2801P-T-1310-ST

2801P-R-ST

Rack and P.S. P/N

3000UA-NN

3000UC-NN

3000CB-NN

3000A-NN-1

Accessory Options

Tx Stand-alone P.S.

+9 Volts DC

Rx Stand-alone P.S.

+9 Volts DC

3RU Rack Chassis

3RU Adapter Card

3RU P.S., Universal AC

3RU P.S., -48 Volts DC

Rack Accessories

Power Supplies

PS090-1

PS090-1

Specifications and Ordering Information

Specifications and Ordering Information

Rev. 3.0, 3/20/07

2020 Kraft Drive, Suite 1000, Blacksburg, VA 24060

USA (800) 732-5252 • TEL (540) 961-1945 • FAX (540) 961-1900

• www.emcore.com

www.forceinc.com

© Copyright 2007. EMCORE Corporation

Information contained herein is deemed to be reliable and accurate as of issue date. EMCORE reserves the right to change the design or specifications of

the product at any time without notice. Ortel, the Ortel logo, EMCORE, and the EMCORE logo are trademarks of EMCORE Corporation.

2801P-T-1310-ST CATV TX

MULTIMODE, 1300 nm

10-300 MHz

orce

Optical Broadcast Systems

SERIAL NUMBER

2020 Kraft Drive, Suite 1000 • Blacksburg, VA 24060

http://www.forceinc.com • Made in USA

MANUFACTURED DATE

2801P-R-ST CATV RX

MULTIMODE, 1300 nm

10-300 MHz

2020 Kraft Drive, Suite 1000 • Blacksburg, VA 24060

http://www.forceinc.com • Made in USA

orce

Optical Broadcast Systems

SERIAL NUMBER

MANUFACTURED DATE

Model 2801 PRO Transmitter & Receiver
