EV Series 1.5 Amp Sensitive SCRs

Sx02xS Series

Packing Options

Dimensions – SOT-223

Dimensions

Inches

Millimeters

Min

Typ

Max

Min

Typ

Max

A

0.248

0.256

0.264

6.30

6.50

6.70

0.130

0.138

0.146

3.30

3.50

3.70

C

—

—

0.071

—

—

1.80

D

0.001

—

0.004

0.02

—

0.10

E

0.114

0.118

0.124

2.90

3.00

3.15

F

0.024

0.027

0.034

0.60

0.70

0.85

G

—

0.090

—

—

2.30

—

H

—

0.181

—

—

4.60

—

I

0.264

0.276

0.287

6.70

7.00

7.30

J

0.009

0.010

0.014

0.24

0.26

0.35

K

10° MAX

Part Number

Marking

Weight

Packing Mode

Base Quantity

Sx02ES

Sx02ES

0.170 g

2500

Sx02ESAP

Sx02ES

0.170 g

Ammo Pack

2000

Sx02ESRP

Sx02ES

0.170 g

Tape & Reel

2000

Sx02TSRP

Sx02TS

0.120 g

Tape & Reel

1000

Note: x = voltage

Dimensions in Millimeters (Inches)

1.5

(0.059”)

1.5

(0.059”)

3.3

(0.130”)

6.4

(0.252”)

4.6

(0.181”)

1.2

(0.047”)

2.3

(0.091”)

(3x)

Pad Layout for SOT-223

Product Selector

Part Number

Voltage

Gate Sensitivity

Package

400V

600V

S402ES

X

—

200μA

TO-92

S602ES

—

X

200μA

TO-92

S402TS

X

—

200μA

SOT-223

S602TS

—

X

200μA

SOT-223

Anode

Gate

Anode

Cathode
