Typical Environmental Speci cations

TEST DESCRIPTION

SPECIFICATION REFERENCE

SHOCK

MIL-STD-202, Method 213, Cond. C (100g, 6ms, Half-Sine)

VIBRATION

MIL-STD-202, Method 201/204 (Random-Sine, 20g)

TEMPERATURE CYCLE

THERMAL SHOCK

MIL-STD-202, Method 107

MOISTURE RESISTANCE

MIL-STD-202, Method 106

SALT ATMOSPHERE

MIL-STD-202, Method 101

ACCELERATION

MIL-STD-883, Method 2001, Condition A (5,000g)

SOLDERABILITY

MIL-STD-202, Method 208 (ANSI-EIA-J-STD-002)

TERMINAL STRENGTH

MIL-STD-202, Method 211 (2lbs)

PIND

MIL-STD-883, Method 2020, Condition A or B (20g, 10g)

FINE LEAK

GROSS LEAK

MIL-STD-202, Method 112, Condition D

RESISTANCE TO SOLVENTS

MIL-STD-202, Method 215

RESISTANCE TO SOLDERING HEAT

MIL-STD-202, Method 210, Condition K

HIGH TEMPERATURE STORAGE

LOW TEMPERATURE STORAGE

MIL-PRF-3098

Vectron is uniquely equipped to

handle all of your special test

requirements. All environmental

and qualification related tests are

performed in house. We’ve

demonstrated compliance and the

ability to test to the requirements

of all governing industry and

military crystal specifications (past

and present).

Some of which include;

• MIL-PRF-3098

• MIL-C-49468

• MIL-C-3098

• TOR-2006 (8583)-5236

• EEE-INST-002

• MIL-PRF-55310

• MIL-STD-202

• MIL-STD-883

• 0THERS

Additional Technical Information

Disclaimer

Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application.

No rights under any patent accompany the sale of any such product(s) or information.

Rev: 12/2009

For Additional Information, Please Contact

USA:

Vectron International

4914 Gray Road

Cincinnati, OH 45232

Tel: 1.513.542.5555

Fax: 1.513.542.5146

Tel: 1.888.328.7661

Europe:

Vectron International

Landstrasse, D-74924

Neckarbischofsheim, Germany

Tel: +49 (0) 3328.4784.17

Fax: +49 (0) 3328.4784.30

Asia:

Vectron International

1F-2F, No 8 Workshop, No 308 Fenju Road

WaiGaoQiao Free Trade Zone

Pudong, Shanghai, China 200131

Tel: 86.21.5048.0777

Fax: 86.21.5048.1881

Typical Wave Solder Reflow Profile (Sn-Pb)

Diagrams of Series and Parallel Resonant Circuits
