ThunderLAN

™ TNETE100PM

PCI ETHERNET

™ CONTROLLER WITH POWER MANAGEMENT

SINGLE-CHIP 10 BASE-T WITH MII FOR 100 BASE-T/100VG-AnyLAN

SPWS026 – OCTOBER 1996

25

POST OFFICE BOX 1443

MECHANICAL DATA

PCM (S-PQFP-G***)

PLASTIC QUAD FLATPACK

4040024 / B 10/94

144 PIN SHOWN

A

73

144

160

0,38

0,22

72

37

NO. OF

PINS***

22,75 TYP

25,35 TYP

0,16 NOM

0,25

0,73

1,03

36

Seating Plane

0,25 MIN

Gage Plane

108

109

144

A

SQ

SQ

31,45

1

28,20

30,95

27,80

3,60

3,20

4,10 MAX

0,10

0,65

M

0,13

NOTES: A. All linear dimensions are in millimeters.

B. This drawing is subject to change without notice.

C. Falls within JEDEC MS-022

D. The 144 PCM is identical to the 160 PCM except that four leads per corner are removed.
