Si87xx

Preliminary Rev. 0.5

21

Open Collector Output with 20 k

 Pullup Resistor (Available in SOIC-8, DIP8, and LGA8)

Si8711AC-B-IS

(In Production)

LED input

Open collector output

with integrated pullup

15 Mbps

HCPL-4506

(Functional Match)

3.75 kVrms

–40 to +125 °C

SOIC-8

Si8711BC-B-IS

(In Production)

High CMTI LED input

Open collector output

with integrated pullup

15 Mbps

HCPL-4506

(Functional Match)

3.75 kVrms

–40 to +125 °C

SOIC-8

Si8711CC-B-IS

(In Production)

LED input

Open collector output

with integrated pullup

1Mbps

HCPL-4506

(Functional Match)

3.75 kVrms

–40 to +125 °C

SOIC-8

Si8711AC-B-IP

(In Production)

LED input

Open collector output

with integrated pullup

15 Mbps

HCPL-4506

3.75 kVrms

–40 to +125 °C

DIP8/GW

Si8711BC-B-IP

(In Production)

High CMTI LED input

Open collector output

with integrated pullup

15 Mbps

HCPL-4506

3.75 kVrms

–40 to +125 °C

DIP8/GW

Si8711CC-B-IP

(In Production)

LED input

Open collector output

with integrated pullup

1Mbps

HCPL-4506

3.75 kVrms

–40 to +125 °C

DIP8/GW

Si8711AD-B-IM

(Sampling)

LED input

Open collector output

with integrated pullup

15 Mbps

HCNW-4506

5.0 kVrms

–40 to +125 °C

LGA8

Si8711BD-B-IM

(Sampling)

High CMTI LED input

Open collector output

with integrated pullup

15 Mbps

HCNW-4506

5.0 kVrms

–40 to +125 °C

LGA8

Si8711CD-B-IM

(Sampling)

LED input

Open collector output

with integrated pullup

1Mbps

HCNW-4506

5.0 kVrms

–40 to +125 °C

LGA8

Table 15. Si87xx Ordering Guide* (Continued)

New Ordering

Part Number

(OPN)

Ordering Options

Input/Output

Configuration

Data Rate

(Cross Reference)

Insulation

Rating

Temp Range

Pkg Type

*Note: All packages are RoHS-compliant. Moisture sensitivity level is MSL3 with peak reflow temperature of 260 °C according

to the JEDEC industry standard classifications and peak solder temperature.
