Preliminary Data Sheet

September 2001

High-Voltage Ringing SLIC for VoIP Applications

L9500A

Agere Systems Inc.

29

48-Pin MLCC

Dimensions are in millimeters.

Notes: The dimensions in this outline diagram are intended for informational purposes only. For detailed schemat-

ics to assist your design efforts, please contact your Agere Sales Representative.

0195mod

PIN #1

IDENTIFIER ZONE

1

7.00

6.75

SEATING PLANE

0.08

0.65/0.80

0.20 REF

DETAIL A

7.00

5.10

± 0.15

3

3.50

3.375

6.75

0.00/0.05

SECTION C–C

11 SPACES @

0.50 = 5.50

0.50 BSC

0.18/0.30

0.30/0.45

0.01/0.05

1.00 MAX

12°

0.18/0.30

0.24/0.60

0.24/0.60

2

1

3

2

0.50 BSC

DETAIL A

CC

VIEW FOR EVEN TERMINAL/SIDE

EXPOSED PAD
