AD8250

Data Sheet

Rev. C | Page 14 of 24

TIME (µs)

2µs/DIV

20mV/DIV

Figure 42. Small Signal Response

G = 2, RL = 2 kΩ, CL = 100 pF

TIME (µs)

2µs/DIV

20mV/DIV

Figure 43. Small Signal Response

G = 5, RL = 2 kΩ, CL = 100 pF

TIME (µs)

2µs/DIV

20mV/DIV

Figure 44. Small Signal Response,

G = 10, RL = 2 kΩ, CL = 100 pF

–50

–55

–60

–65

–70

–75

–80

–85

–90

–95

–100

–105

–110

–115

–120

100

10k

100k

FREQUENCY (Hz)

G = 1

G = 2

G = 5

G = 10

Figure 45. Total Harmonic Distortion + Noise vs. Frequency,

10 Hz to 22 kHz Band-Pass Filter, RL = 2 kΩ

–50

–60

–70

–80

–90

–100

–110

100

10k

100k

FREQUENCY (Hz)

G = 1

G = 2

G = 5

G = 10

Figure 46. Total Harmonic Distortion + Noise vs. Frequency,

10 Hz to 500 kHz Band-Pass Filter, RL = 2 kΩ
