CC1150

SWRS037A

Page 1 of 60

CC1150

Low Power Sub-1 GHz RF Transmitter

Applications

• Ultra low power UHF wireless transmitters

• Operating in the 315/433/868/915 MHz

ISM/SRD bands

• AMR – Automatic Meter Reading

• Consumer Electronics

• RKE – Remote Keyless Entry

• Low power telemetry

• Home and building automation

• Wireless alarm and security systems

• Industrial monitoring and control

• Wireless sensor networks

Product Description

The

CC1150 is a low cost true single chip UHF

transmitter designed for very low power

wireless applications. The circuit is mainly

intended for the ISM (Industrial, Scientific and

Medical) and SRD (Short Range Device)

frequency bands at 315, 433, 868 and 915

MHz, but can easily be programmed for

operation at other frequencies in the 300-348

MHz, 400-464 MHz and 800-928 MHz bands.

The RF transmitter is integrated with a highly

configurable

baseband

modulator.

The

modulator

supports

various

modulation

formats and has a configurable data rate up to

500 kBaud. The

CC1150 provides extensive

hardware support for packet handling, data

buffering and burst transmissions.

The main operating parameters and the 64-

byte transmit FIFO of

CC1150 can be controlled

via an SPI interface. In a typical system, the

CC1150 will be used together with a micro-

controller and a few additional passive

components.

CC1150 is part of Chipcon’s SmartRF®04

technology platform based on 0.18 µm CMOS

technology.

Key Features

•

Small size (QLP 4x4 mm package, 16

pins)

•

True single chip UHF RF transmitter

•

Frequency bands: 300-348 MHz, 400-464

MHz and 800-928 MHz

•

Programmable data rate up to 500 kBaud

•

Low current consumption

•

Programmable output power up to +10

dBm for all supported frequencies

•

Programmable baseband modulator

•

Ideal for multi-channel operation

•

Very

few

external

components:

Completely on-chip frequency synthesizer,

no external filters needed

•

Configurable packet handling hardware

•

Suitable for frequency hopping systems

due to a fast settling frequency synthesizer

•

Optional Forward Error Correction with

interleaving

•

64-byte TX data FIFO
