background image
CC1150
SWRS037A
Page 9 of 60
4.5
Analog Temperature Sensor
Tc = 25
°C, VDD = 3.0 V if nothing else is stated. Note that it is necessary to write 0xBF to the PTEST register to use the
analog temperature sensor in the IDLE state.
Parameter
Min
Typ
Max
Unit
Condition/Note
Output voltage at –40
°C
0.651
V
Output voltage at 0
°C
0.747
V
Output voltage at +40
°C
0.847
V
Output voltage at +80
°C
0.945
V
Temperature coefficient
2.45
mV/
°C
Fitted from –20
°C to +80°C
Absolute error in calculated
temperature
–2
*
2
*
°C
From –20
°C to +80°C when using 2.45 mV / °C,
after 1-point calibration at room temperature
* Indicated minimum and maximum error with 1-
point calibration is based on simulated values for
typical process parameters
Current consumption
increase when enabled
0.3
mA
Table 8: Analog Temperature Sensor Parameters
4.6
DC Characteristics
Tc = 25
°C if nothing else stated.
Digital Inputs/Outputs
Min
Max
Unit
Condition
Logic "0" input voltage
0
0.7
V
Logic "1" input voltage
VDD-0.7
VDD
V
Logic "0" output voltage
0
0.5
V
For up to 4 mA output current
Logic "1" output voltage
VDD-0.3
VDD
V
For up to 4 mA output current
Logic "0" input current
N/A
–1
µA
Input equals 0 V
Logic "1" input current
N/A
1
µA
Input equals VDD
Table 9: DC Characteristics
4.7
Power on Reset
For proper Power-On-Reset functionality, the power supply must comply with the requirements in
Table 10 below. Otherwise, the chip should be assumed to have unknown state until transmitting
an SRES strobe over the SPI interface. See section 16.1 on page 31 for a description of the
recommended start up sequence after turning power on.
Parameter
Min
Typ
Max
Unit
Condition/Note
Power-up ramp-up time
5
ms
From 0 V until reaching 1.8 V
Power off time
1
ms
Minimum time between power-on and power-off
Table 10: Power-on Reset Requirements
