MMA-283136-R5

28-31GHz 4W MMIC Power Amplifier

Data Sheet

October, 2012

MicroWave Technology, Inc. an IXYS Company, 4268 Solar Way, Fremont, CA 94538

510-651-6700

FAX

510-651-2208 WEB www.mwtinc.com

Please visit MwT website www.mwtinc.com for information on other MwT MMIC products.

Page 2 of 13

Electrical Specifications: Vds=6V, Vgs=-0.85V, Idsq=2000mA, Ta=25 C Z0=50 ohm

Parameter

Units

Typical Data

Frequency Range

GHz

28-31

Gain (Typ / Min)

22 / 20

Gain Flatness (Typ / Max)

+/-dB

2.5 / 3

Input RL(Typ/Max)

10/8

Output RL(Typ/Max)

10/8

Output P1dB(Typ/Min)

dBm

35/34

Output P3dB(Typ/Min)

dBm

36/35

IM3 Level (1)

dBc

-40

Thermal Resistance

⁰C/W

3.8

Operating Current at P1dB(Typ /

Max)

2500 / 3000

(1) Output IP3 is measured with two tones at output power of 20 dBm/tone separated by 20 MHz
