AD8305
Rev. B | Page 9 of 24
IPD (A)
1.5
–2.0
1n
1.0
0.5
0
–0.5
–1.0
–1.5
10n
1µ
100n
10µ
100µ
1m
TA = 25°C
2.0
MEAN + 3σ
MEAN – 3σ
10m
Figure 21. Law Conformance Error Distribution (3σ to Either Side of Mean)
1.5
–2.0
1.0
0.5
0
–0.5
–1.0
–1.5
2.0
MEAN + 3σ @ 70°C
IPD (A)
1n
10n
100n
1µ
10µ
100µ
1m
10m
MEAN ± 3σ @0°C
MEAN – 3σ @ 70°C
TA = 0°C, 70°C
Figure 22. Law Conformance Error Distribution (3σ to Either Side of Mean)
IPD (A)
3
–4
1n
2
1
0
–1
–2
–3
10n
100n
1µ
10µ
100µ
1m
10m
4
TA = –40°C, +85°C
MEAN + 3σ @ –40°C
MEAN – 3σ @ –40°C
MEAN ± 3σ @ +85°C
Figure 23. Law Conformance Error Distribution (3σ to Either Side of Mean)
TEMPERATURE (°C)
20
15
10
5
0
–5
–10
–15
–20
MEAN + 3σ
MEAN – 3σ
–25
90
80
60
40
20
0
–20
10305070
–10
–30
–40
Figure 24. VREF Drift vs. Temperature (3σ to Either Side of Mean)
20
15
10
5
0
–5
–10
–15
–20
MEAN + 3σ
MEAN – 3σ
TEMPERATURE (°C)
90
80
60
40
20
0
–20
10305070
–10
–30
–40
Figure 25. VREF − VIREF Drift vs. Temperature (3σ to Either Side of Mean)
5
4
3
2
1
0
–1
–2
–3
–4
–5
TEMPERATURE (°C)
90
80
60
40
20
0
–20
10305070
–10
–30
–40
MEAN + 3σ
MEAN – 3σ
Figure 26. VINPT Drift vs. Temperature (3σ to Either Side of Mean)
