BEZELS

Page 2

Specifications may be changed without

prior notice. Printing error reserved

Ordering

viewing area

bezel size

cutout

studs matching lcd-module

information

A

B

C

D

E

F

G

dotmatrix / graphic

EA 017-1U

63,5 12,8

79,5 25,0

69,7 19,2

74,5

EA 7161-A

1x16

EA 017-2U

60,0 14,8

76,0 27,0

66,2 21,2

71,0

EA 7162

2x16

EA 017-3

131,5 13,0

147,5 25,2

137,7 19,4

142,5

(EA 7321)

1x32

EA 017-4U

153,0 14,8

169,0 27,0

159,2 21,2

164,0

EA 7402

2x40

EA 017-5

140,0 15,8

156,0 28,0

146,2 22,2

151,0

EA 7322-B

2x32

EA 017-6U

98,5 12,8

114,5 25,0

104,7 19,2

109,5

EA 7161-E

1x16

EA 017-7U

81,5 17,2

97,5 29,4

87,7 23,6

92,5

EA 7202

2x20

EA 017-8U

60,8 24,2

76,8 36,4

67,0 30,6

71,8

EA 7164

4x16

EA 017-9U

75,0 24,2

91,0 36,4

81,2 30,6

86,0

EA 7204

4x20

EA 017-10U

131,0 38,0

147,0 50,2

137,2 44,4

142,0

EA 7240-6

240x64

EA 017-12U

97,4 22,4

113,4 34,6

103,6 28,8

108,4

EA 7162-B

2x16

EA 017-13U

145,0 28,0

161,0 40,2

151,2 34,4

156,0

EA 7404

4x40

EA 017-14U

92,0 14,8

108,0 27,0

98,4 21,2

103,0

EA 7242

2x24

EA 017-15U

68,0 68,0

84,0 80,2

74,2 74,4

79,0

EA VK-2128

128x128

EA 017-16U

75,0 39,0

91,0 51,2

81,2 45,4

86,0

EA VK-2080

160x80

EA 017-17U

58,0 32,5

74,0 44,7

64,2 38,9

69,0

EA VK-2064

128x64

EA 017-18U

99,5 80,5

115,5 92,7

105,7 86,9

110,5

EA VK-5160

160x128

EA 017-23

121,0 12,0

137,0 24,2

127,2 18,4

132,0

EA 8201-B

1x20

EA 017-25

121,0 41,5

137,0 53,7

127,2 47,9

132,0

EA 8204-B

4x20

EA 017-27

145,0 33,8

161,0 46,0

151,2 40,2

156,0

EA 8202-C

2x20

EA 017-28

145,0 63,9

161,0 76,1

151,2 70,3

156,0

EA 8204-C

4x20

The panel cutout should be 0.2 to 0.5 mm larger than dimension EF. The bezel is centered to the

cutout by 2 studs with 2mm diameter.

(all dimensions in mm)

BEZELS FOR DOTMATRIX MODULES

EA 017-xxU AND EA 017-xx SERIES

(This drawing shows the snap in holders for acrylic or

glass. Within EA 017-xx series there are no snap-in holder)
