1 / 3 page

Elektronische Bauelemente

2SD602 / 2SD602A

NPN Plastic-Encapsulate Transistor

04-Mar-2011 Rev. B

Page 1 of 3

http://www.SeCoSGmbH.com/

Any changes of specification will not be informed individually.

1

Base

2

Emitter

Collector

3

RoHS Compliant Product

A suffix of “-C” specifies halogen & lead-free

FEATURE

Low collector to emitter saturation voltage VCE(sat)

CLASSIFICATION OF hFE (1)

Product-Rank

2SD602-Q

2SD602-R

2SD602-S

Range

85~170

120~240

170~340

Marking Code

WQ1

WR1

WS1

Product-Rank

2SD602A-Q

2SD602A-R

2SD602A-S

Range

85~170

120~240

170~340

Marking Code

XQ

XR

XS

PACKAGE INFORMATION

Package

MPQ

LeaderSize

SOT-23

3K

7’ inch

ABSOLUTE MAXIMUM RATINGS (TA = 25°C unless otherwise specified)

Parameter

Symbol

Ratings

Unit

2SD602

30

Collector to Base Voltage

2SD602A

VCBO

60

V

2SD602

25

Collector to Emitter Voltage

2SD602A

VCEO

50

V

Emitter to Base Voltage

VEBO

5

V

Collector Current - Continuous

IC

500

mA

Collector Power Dissipation

PC

200

mW

Thermal Resistance From Junction to Ambient

RθJA

625

°C / W

Junction, Storage Temperature

TJ, TSTG

150, -55~150

°C

SOT-23

Top View

A

L

C B

D

G

H

J

F

K

E

1

2

3

1

2

3

Millimeter

REF.

Min.

Max.

REF.

Min.

Max.

A

2.80

3.04

G

0.09

0.18

B

2.10

2.55

H

0.45

0.60

C

1.20

1.40

J

0.08

0.177

D

0.89

1.15

K

0.6 REF.

E

1.78

2.04

L

0.89

1.02

F

0.30

0.50
