2 / 10 page

PS8601, PS8601L

PACKAGE DIMENSIONS (Unit: mm)

10.16 MAX.

1.34

1.27

MAX.

2.54

0.50 ± 0.10

0.25 M

7.62

0 to 15o

Output

PIN CONNECTIONS (Top View)

DIP (Dual In-line Package)

Lead Bending type (Gull-wing)

PS8601L

Input

1. NC

2. Anode

3. Cathode

4. NC

5. Emitter

6. VO

7. Base

8. VCC

10.16 MAX.

2.54

1.34 ± 0.10

0.25 M

7.62

1.27

MAX.

0.9

± 0.25

9.60 ± 0.4

Output

PIN CONNECTIONS (Top View)

Input

1. NC

2. Anode

3. Cathode

4. NC

5. Emitter

6. VO

7. Base

8. VCC

10.16 MAX.

1.34

1.27 MAX.

2.54

0.50 ± 0.10

0.25 M

7.62

0 to 15o

10.16

10.16 MAX.

PS8601L1

Lead Bending type (for long distance)

PS8601L2

2.54

1.34 ± 0.10

0.25 M

7.62

10.16

11.8 ± 0.4

1.27 MAX.

0.9 ± 0.25

PS8601
