2 / 4 page  SMD Type www.kexin.com.cn 2 Transistors PNP Transistors 2SA1514K ■ Typical Characterisitics 10 100 1000 10000 -0.1 -1 -10 -100 VCE= －6V Ta=100ºC 25ºC － 40ºC -0.1 -1 -10 0 -0.5 -1 -1.5 -2 VCE= －6V Ta=－40ºC 25ºC 100ºC 10 100 1000 10000 -0.1 -1 -10 -100 Ta=25ºC VCE= －5V － 3V － 1V Fig.1 Ground Emitter Propagation Characteristics BASE TO EMITTER VOLTAGE : VBE [V] Fig.2 Typical Output Characteristics COLECTOR TO EMITTE VOLTAGE : VCE [V] Fig.3 DC Current Gain vs. Collector Current(I) COLLECTOR CURRENT : IC [mA] Fig.4 DC Current Gain vs. Collector Current(II) COLLECTOR CURRENT : IC [mA] |
|
|
