Specifications HCTS393MS

TABLE 2. AC ELECTRICAL PERFORMANCE CHARACTERISTICS

PARAMETER

SYMBOL

(NOTES 1, 2)

CONDITIONS

GROUP

A SUB-

GROUPS

TEMPERATURE

LIMITS

UNITS

MIN

MAX

CPn to Q0

TPHL

TPLH

VCC = 4.5V

9

2

29

ns

10, 11

2

34

ns

CPn to Q1

TPHL

TPLH

VCC = 4.5V

9

2

36

ns

10, 11

2

43

ns

CPn to Q2

TPHL

TPLH

VCC = 4.5V

9

2

43

ns

10, 11

2

52

ns

CPn to Q3

TPHL

TPLH

VCC = 4.5V

9

2

49

ns

10, 11

2

59

ns

MR to Qn

TPHL

VCC = 4.5V

9

2

30

ns

10, 11

2

34

ns

NOTES:

1. All voltages referenced to device GND.

2. AC measurements assume RL = 500

Ω, CL = 50pF, Input TR = TF = 3ns, VIL = GND, VIH = 3V.

TABLE 3. ELECTRICAL PERFORMANCE CHARACTERISTICS

PARAMETER

SYMBOL

CONDITIONS

NOTES

TEMPERATURE

LIMITS

UNITS

MIN

MAX

Capacitance Power

Dissipation

CPD

VCC = 5.0V, f = 1MHz

1

-

39

pF

1

-

60

pF

Input Capacitance

CIN

VCC = 5.0V, f = 1MHz

1

-

10

pF

1

-

10

pF

Output Transition

Time

TTHL,

TTLH

VCC = 4.5V

1

-

15

ns

1

-

22

ns

Max Operating

Frequency

FMAX

VCC = 4.5V

1

-

27

MHz

1

-

18

MHz

Pulse Width Clock

TW

(CP)

VCC = 4.5V

1

-

ns

1

-

ns

Pulse Width Reset

TW

(R)

VCC = 4.5V

1

-

ns

1

-

ns

Recovery Time

Reset

TREC

VCC = 4.5V

1

-

ns

1

-

ns

NOTE:

1. The parameters listed in Table 3 are controlled via design or process parameters. Min and Max Limits are guaranteed but not directly

tested. These parameters are characterized upon initial design release and upon design changes which affect these characteristics.
