µPD6124A, 6600A

25

(2)

µPD6600A Electrical Specifications

Parameter

Symbol

Ratings

Unit

Supply Voltage

–0.3 to +7.0

V

Input Voltage

V

Operating Ambient Temperature

–20 to +75

°C

Storage Temperature

–40 to +125

°C

Caution

Even if one of the parameters exceeds its absolute maximum rating even momentarily, the quality

of the product may be degraded. The absolute maximum rating therefore specifies the upper or lower

limit of the value at which the product can be used without physical damages. Be sure to use the

product(s) within the ratings.

Parameter

Symbol

MIN.

TYP.

MAX.

Unit

Supply Voltage

2.2

3.6

V

Oscillation Frequency

400

500

kHz
