µPD6124A, 6600A

6

5.

the control register.

Table referencing for ROM data can be easily executed by calling the ROM contents by setting the ROM address

to the data pointer.

On reset or “all clear” is input, it becomes undefined.

Figure 5-1. Data Pointer Organization

Control registers

(P )

1

Note

6.

ACCUMULATOR (A) ……… 4 BITS

The accumulator (A) is a 4-bit register. The accumulator plays a major role in each operation.

On reset or “all clear” is input, it becomes undefined.

Figure 6-1. Accumulator Organization

A

7.

ARITHMETIC LOGIC UNIT (ALU) ……… 4 BITS

The arithmetic logic unit (ALU) is a 4-bit operation circuit, and executes simple operations, such as arithmetic

operations.

8.

FLAGS

(1)

Status flag

When the status for each pin is checked by the STTS instruction, if the condition coincides with the condition

specified by the STTS instruction, the status flag (F) is set (to 1).

On reset or “all clear” is input, it becomes undefined.

(2)

Carry flag

When the INC (increment) instruction or the RL (rotate left) instruction is executed, if a carry is generated from

the MSB for the accumulator, the carry flag (C) is set (to 1).

The carry flag (C) is also set (to 1), if the contents for the accumulator are “FH”, when the SCAF instruction

is executed.

On reset or “all clear” is input, it becomes undefined.
