Part Description

Specifications subject to change without notice.

n North America: Tel. (800) 366-2266

n Asia/Pacific: Tel.+81-44-844-8296, Fax +81-44-844-8298

n Europe: Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020

4

3.4 V, 1.2 W RF Power Amplifier IC

MA02107AF

V 1.0

Application Schematic

RF INPUT

RF OUTPUT

C1

C2

T1

L1

C5

C4

N/C

N/C

N/C

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

C3

List of components:

C1 = 0.1µF Kemet multilayer ceramic chip capacitor (C1206C104K5RAC)

C2 = 4700 pF Kemet multilayer ceramic chip capacitor (C0805C472K5RAC)

C4 = 6.8 pF DLI multilayer ceramic chip capacitor (C11AH7R5B5TXL)

C3 = C5 = 100 pF DLI multilayer ceramic chip capacitor (DC Block; C11AH101K5TXL)

L1 = 39 nH Coilcraft chip inductor (1008CS.390XMBB)

T1 = 0.19" of 50 ohm grounded coplanar waveguide (60 mil GETEK board)

TSSOP-16 Package

Dimensions in

millimeters

Dimensions in inches

SYMBOL

MIN

NOM

MAX

MIN

NOM

MAX

A

1.05

1.10

1.20

0.041

0.043

0.047

A1

0.05

0.10

0.15

0.002

0.004

0.006

A2

—

1.00

1.05

—

0.039

0.041

b

0.20

0.25

0.28

0.008

0.010

0.011

C

—

0.127

—

—

0.005

—

D

4.90

5.075

5.10

0.193

0.200

0.201

E

6.20

6.40

6.60

0.244

0.252

0.260

E1

4.30

4.40

4.50

0.169

0.173

0.177

e

—

0.65

—

—

0.025

—

L

0.50

0.60

0.70

0.020

0.024

0.028

L1

0.90

1.00

1.10

0.035

0.039

0.043

y

—

—

0.10

—

—

0.004

θ

0°

4°

8°

0°

4°

8°

NOTES:

1.

Controlling dimension: mm

2.

Lead frame material: EFTEC 64

3.

Dimension “D” does not include mold flash, protrusions or gate burrs

4.

Dimension “E” does not include interlead flash or protrusions

5.

Tolerance: ±0.254 mm (

±0.010″) unless otherwise specified

6.

End flash max: 0.12 mm (0.005

″)
