IX2204

5.5 Mechanical Dimensions

5.5.1 IX2204NE 16-Pin Narrow SOIC Package

5.5.2 IX2204NETR Tape & Reel Packaging for 16-Pin Narrow SOIC Package (TBD)

NOTES:

1. All dimensions are MM (IN)

2. Reference JEDEC outline: MS-012 BC Rev F. (Thermal)

3. Dimension does not include mold flash, protrusions,

or gate burrs. Mold flash, protrusions, and gate burrs

shall not exceed 0.15 (0.006) per side.

4. Dimension does not include inter-lead flash, and

protrusions shall not exceed 0.25 (0.010) per side.

DIMENSIONS

mm

(inches)

9.90 BSC

(0.390 BSC)

See Note 3

1.27 TYP

(0.05 TYP)

0.31 - 0.51

(0.012 - 0.020)

3.90 BSC

(0.154 BSC)

See Note 4

1.25 min

(0.049 min)

0.00 - 0.15

(0.000 - 0.006)

1.70 max

(0.067 max)

6.00 ± 0.50 BSC

(0.236 ± 0.020 BSC)

0.20 TYP

(0.008 TYP)

0.80 ± 0.50

(0.031 ± 0.020)

0º - 8º

3.86 - 4.57

(0.152 - 0.180)

1.68 - 2.41

(0.066 - 0.095)

Recommended PCB Pattern

5.50

(0.217)

1.70

(0.059)

0.60

(0.024)

1.27

(0.05)

4.55

(0.179)

2.40

(0.094)

Dimensions

mm

(inches)

NOTES:

1.10 Sprocket hole pitch cumulative tolerance ±0.2

2. Camber in compliance with EIA 481

3. Pocket position relative to sprocket hole measured

as true position of pocket, not pocket hole

Embossment

Embossed Carrier

Top Cover

Tape Thickness

0.102 MAX.

(0.004 MAX.)

330.2 DIA.

(13.00 DIA.)

K

(0.083 ± 0.004)

0.30 ± 0.05

(0.012 ± 0.002)

R 0.3 max

2.00 ± 0.10 Note 3

(0.079 ± 0.004)

4.00 Note 1

(0.157)

8.00 ± 0.10

(0.315 ± 0.004)

∅ 1.5 +0.1 / -0.0

∅ 1.50 min

R 0.5 typ

A

A

Section A-A

1.75 ± 0.10

(0.069 ± 0.004)

7.5 ± 0.10 Note 3

(0.295 ± 0.004)

A

(0.256 ± 0.004)

B

(0.406 ± 0.004)

16.0 ± 0.3

(0.63 ± 0.012)
