FERRITE WIRE WOUND INDUCTORS

AISC-0603F

STANDARD SPECIFICATIONS:

APPLICATIONS:

FEATURES:

1.6 x 1.0 x 1.0mm

ABRACON IS

ISO 9001 / QS 9000

CERTIFIED

ABRACON IS

ISO 9001 :2008

CERTIFIED

30332 Esperanza, Rancho Santa Margarita, California92688

Visit www.abracon.com for Terms & Conditions of Sale

• Camcorders, LED TVs and other electronic devices

• Higher inductance values than other 0603 inductors

• Ferrite construction for high current rating

• Inductance values: 47 nH – 22 μH; 5% tolerance available

Revised: 10.11.13

Part Number

AISC-0603F-

Inductance Code

Inductance

Tolerance

L Test

Freq.

Max. DC

Resistance

Max. Rated

Current

Min. Self-resonant

Frequency

Units

nH

-

MHz

Ω

mA

MHz

Symbol

L

-

Freq.

DCR

Ir

S.R.F

AISC-0603F-47N

47

J, K, M

7.9

0.06

1200

2350

AISC-0603F-51N

51

J, K, M

7.9

0.07

1050

2300

AISC-0603F-R10

100

K, M

7.9

0.11

850

1370

AISC-0603F-R12

120

J, K, M

7.9

0.18

670

1340

AISC-0603F-R15

150

J, K, M

7.9

0.12

820

1260

AISC-0603F-R18

180

J, K, M

7.9

0.19

670

1060

AISC-0603F-R20

200

J, K, M

7.9

0.14

740

1030

AISC-0603F-R22

220

J, K, M

7.9

0.20

650

850

AISC-0603F-R24

240

J, K, M

7.9

0.17

690

800

AISC-0603F-R25

250

J, K, M

7.9

0.17

690

910

AISC-0603F-R27

270

J, K, M

7.9

0.24

630

780

AISC-0603F-R33

330

J, K, M

7.9

0.29

510

730

AISC-0603F-R39

390

J, K, M

7.9

0.33

490

750

AISC-0603F-R47

470

J, K, M

7.9

0.37

470

670

AISC-0603F-R50

500

J, K, M

7.9

0.45

410

610

AISC-0603F-R56

560

J, K, M

7.9

0.51

380

590

AISC-0603F-R62

620

J, K, M

7.9

0.48

390

570

AISC-0603F-R65

650

J, K, M

7.9

0.61

350

550

AISC-0603F-R68

680

J, K, M

7.9

0.77

310

520

AISC-0603F-R78

780

J, K, M

7.9

0.83

300

480

AISC-0603F-R82

820

J, K, M

7.9

0.88

290

500

AISC-0603F-1R0

1000

J, K, M

7.9

0.94

280

410

AISC-0603F-1R2

1200

J, K, M

7.9

1.10

260

370

AISC-0603F-1R5

1500

J, K, M

7.9

1.30

240

340

AISC-0603F-1R8

1800

J, K, M

7.9

1.40

230

190

AISC-0603F-2R2

2200

J, K, M

7.9

1.50

220

120

AISC-0603F-2R7

2700

J, K, M

7.9

1.60

210

70

AISC-0603F-3R3

3300

J, K, M

7.9

1.80

200

60

AISC-0603F-3R9

3900

J, K, M

7.9

1.90

190

50

AISC-0603F-4R7

4700

J, K, M

7.9

2.70

160

50

AISC-0603F-5R6

5600

J, K, M

7.9

3.00

150

40

AISC-0603F-6R8

6800

J, K, M

7.9

4.00

130

40

AISC-0603F-7R8

7800

J, K, M

7.9

4.40

120

40

AISC-0603F-8R2

8200

J, K, M

7.9

4.50

110

40

AISC-0603F-100

10000

J, K, M

2.5

5.00

100

30

AISC-0603F-150

15000

J, K, M

2.5

9.50

90

20

AISC-0603F-180

18000

J, K, M

2.5

10.40

80

20

AISC-0603F-220

22000

J, K, M

2.5

11.40

70

20
